Références
| SKU | Finishing stage | Pkg | Delay (d) |
|---|---|---|---|
| 3ES92038 | 9005-30% | 100 | 7 |
| 3ES91038 | 9016-80% | 100 | 7 |
| 3ES92038RAL |
|
1 | 14 |
Information
Commentaire
To be fitted
Astuce
Tube length calculation:
tube length = total length of the Espagnolette bolt – 90 mm.
tube length = total length of the Espagnolette bolt – 90 mm.
